Some M4/3 cameras (like the GH4) and lenses are not that much smaller than cropped sensor DSLRs and since I haven’t shot very much with M4/3 gear my comments in this section are based on my experience shooting with the Nikon 1 system.
When facing low light situations a photographer’s ability to shoot at slow shutter speeds while using a smaller and lighter camera system can be a distinct advantage and can allow the photographer to shoot at lower ISO’s. This is especially true when photographing static subjects. In order to demonstrate this functionality I did a number of hand-held test images while sitting at my desk. I kept my elbows tucked into my chest and took three images each at various shutter speeds. What you’ll see in the following portion of the article is the best image I captured from each set of three test images.
As you look at these images it is important to remember the rule of reciprocity in photography. While fairly technical in nature the basic thing to remember is to maintain an appropriate minimum shutter speed based on the focal length of the lens with which you are shooting. If you’re using a 400 mm lens the minimum shutter speed is 1/400th. A 200 mm lens would require a minimum of 1/200th and so on. This does NOT include the effects of vibration reduction or image stabilization that may be in your lens or camera body.
When you read that the VR on a particular lens provides a 3-stop advantage it simply means that the lens can be shot hand-held at a shutter speed equivalent to 3 stops of light slower. For example a 400 mm lens would have a minimum recommended shutter speed of 1/400th. If it has VR that provides a 3-stop advantage that lens should be able to be shot hand-held at 1/50th of a second (1/400 / 2 = 1/200 /2 = 1/100 / 2 = 1/50).
Some folks recommend that you apply the crop factor to your lens to determine the minimum shutter speed at which you should shoot when using lenses designed for smaller sensor cameras. I do not agree with this advice at all and will try to demonstrate this with the test images.
Let’s start with some images taken with a Nikon 1 32 mm f/1.2 lens which does not have VR. All images were taken at ISO-200 in aperture priority. Here is the first image taken at f/1.2 1/80…as would be expected it is decently sharp.
Now let’s look at the next one taken at f/1.8 1/40…still pretty sharp.
Now f/2 1/30…still holding (all three test images at this speed were identical).
Here’s f/2.8 at 1/15…we’re still hanging in there (2 of 3 at this speed were identical, 1 a bit soft).
Now f/4 at 1/8…at this point I’m starting to lose it.
Pushing it further at f/5.6 at 1/4 second…the best of three attempts and not very good.
And, finally the best of three attempts at f/8 at 1/2 second…pretty bad.
The important point in all of this is the fact that smaller sensor cameras and their system lenses are much easier to shoot hand-held at slower shutter speeds when compared to full frame gear. Obviously you have to adjust your hand-holding technique quite a bit, especially your finger movement on the shutter.
The Nikon 1 32 mm f/1.2 has an equivalent field-of-view of 86 mm when compared to full frame. I can tell you from personal experience there is absolutely no way that I could have hand-held my Nikkor 85 mm f/1.8 when mounted on my D800 and got anything sharp at 1/30th of a second…and not even remotely close to sharp at 1/15th of a second.
Regardless of what else you may read… a 32 mm lens is always a 32 mm lens in my opinion. I do not believe that you need to apply any kind of crop factor to it to estimate the minimum shutter speed at which you should be able to shoot with it hand held. That’s why I was able to get 3 out of 3 usable images at 1/30 of a second and 2 out of 3 usable images at 1/15 even though the lens does not have VR.
No doubt some folks will disagree with my view on this point. I just base it on what I routinely experience first hand day in and day out when shooting with Nikon 1 cameras. It has been this way since the first day I started shooting with them. Perhaps this is one of those situations where there is a disconnect between photography theory and the real world.
Now let’s look at a few test shots using some Nikon 1 zoom lenses. Again, all images were shot at ISO-200. The first image was taken with a Nikon 1 30-110 f/3.8-5.6 VR lens. This has an equivalent field-of-view of 297 mm when compared to a full frame camera. But remember… it is still only a 110 mm lens and shoots like one in terms of minimum hand-holding shutter speed. This first image was taken at f/5.6, 1/4 second with the lens fully extended to 110 mm.
Hmmm… that looks like about a 4-stop advantage for the VR on that lens. Let’s look at another shot with the same lens fully extended, this time shot at f/8 at 1/2 second…
Let’s think about this for a moment… the 30-110 mm provides an equivalent field-of-view of about 300 mm. If I was shooting with a 300 mm full frame lens with VR that had a 4-stop advantage on a full frame body I’d be able to shoot at about 1/20th of a second best case. Going from 1/20th down to 1/4 of a second is about a 2-stop advantage for the 30-110 mm CX lens. Depending on the situation that could make the difference in shooting at ISO-400 rather than at ISO-1600 with full frame gear.
